compactador neumatico Caterpillar PS150-C año 2007 disponible entrega inmediata
¡Gracias por tu visita! Si tienes más preguntas o necesitas ayuda adicional, no dudes en contactarnos. Estamos aquí para asegurarnos de que encuentres exactamente lo que necesitas.
The Caterpillar PS150-C, released in 2007, is a pneumatic tire roller commonly used for compaction in road construction and maintenance projects. Here are the specifications for the 2007 Caterpillar PS150-C:
General Specifications
-
Manufacturer: Caterpillar
-
Model: PS150-C
-
Type: Pneumatic Tire Roller
-
Year: 2007
Engine Specifications
-
Engine Model: Caterpillar 3054C
-
Engine Type: 4-cylinder, turbocharged diesel engine
-
Gross Power: Approximately 100 hp (74.6 kW)
-
Net Power: Approximately 97 hp (72.3 kW)
Operating Specifications
-
Operating Weight:
-
Light Ballast: Approximately 7,622 kg (16,800 lbs)
-
Maximum Ballast: Up to 15,195 kg (33,500 lbs)
-
-
Working Width: Approximately 2,080 mm (81.9 in)
-
Compaction Width: 2,080 mm (81.9 in)
-
Tire Configuration:
-
Number of Tires: 9 (4 front, 5 rear)
-
Tire Size: 7.50 x 15-6PR (front and rear)
-
Performance Specifications
-
Travel Speed (Max): Up to 19.2 km/h (11.9 mph)
-
Compaction Force:
-
Static Linear Load (minimum): Approximately 1,200 kg/m (809 lbs/ft)
-
Static Linear Load (maximum): Approximately 2,395 kg/m (1,610 lbs/ft)
-
Dimensions
-
Overall Length: Approximately 4,820 mm (189.8 in)
-
Overall Width: Approximately 2,235 mm (88 in)
-
Overall Height: Approximately 3,000 mm (118.1 in) with ROPS
-
Wheelbase: 3,100 mm (122 in)
-
Turning Radius (Inside): 5,450 mm (214.6 in)
Additional Features
-
Transmission: Hydrostatic transmission with variable speed control
-
Steering: Articulated steering for better maneuverability
-
Brakes: Hydraulic braking system
-
Ballast Options: The machine can be ballasted with sand, water, steel, or other materials to achieve desired compaction force.
-
Operator Cab: ROPS (Roll-Over Protective Structure) with optional enclosed cab with climate control
